Analog Circuits and Signal Processing

Kilani, Dima; Mohammad, Baker; Alhawari, Mohammad; Saleh, Hani; Ismail, Mohammed

This book describes power management integrated circuits (PMIC), for power converters and voltage regulators necessary for energy efficient and small form factor systems. The authors discuss state-of-the-art PMICs not only for battery powered wearable devices, but also energy harvesting-based devices. The circuits presented support voltage scaling to reduce the overall average power consumption of a wearable device, resulting in longer device operating time. The discussion includes many designs, control techniques and approaches to distribute efficiently the power among different blocks in the device.

• Demonstrates for readers how to innovate in designing power management integrated circuits (PMIC) suitable for wearable devices, powered by either battery or harvesting energy;

• Introduces a dual outputs switched capacitor, using a single voltage regulator to minimize the area overhead and discusses the effect of having more than two outputs on the area and power efficiency;

• Introduces a novel clock-less digital LDO regulator that eliminates the use of the clocked comparator and serial shift register in the conventional design;

• Presents experimental results of energy harvesting-based power management units (PMU), using different combinations of power converters and voltage regulators, providing a guide for designers to select the appropriate option based on device requirements.

Details

Published by: Springer

Publication Date: 2020-01-18

Format: Hardcover

ISBN-13: 9783030378837

DOI: 10.1007/978-3-030-37884-4

Dimensions: 235cm x155cm

Pages: 103
