Synthesis Lectures on Engineering, Science, and Technology: Open-Source Automated Analog Layout Design

Ratschenberger, Jakob; Pretl, Harald

This book shows how the layout of an analog circuit can be automatically generated in a fully open-source way. Based on an exemplary design flow, it introduces and explains the necessary steps for transforming a SPICE netlist into a layout, which can be inspected by the open-source layout editor Magic VLSI. This is done by using the industry’s first open-source process design kit SKY130. Furthermore, the implementation of the design flow in the programming language Python is available as open-source on GitHub.

​​​​​​​

Details

Published by: Springer

Publication Date: 2025-01-11

Format: Hardcover

ISBN-13: 9783031685613

DOI: 10.1007/978-3-031-68562-0

Dimensions: 240cm x168cm

Pages: 120
