Operational Amplifiers: Theory and Design

Huijsing, Johan

This proven textbook guides readers to a thorough understanding of the theory and design of operational amplifiers (OpAmps). The core of the book presents systematically the design of operational amplifiers, classifying them into a periodic system of nine main overall configurations, ranging from one gain stage up to four or more stages. This division enables circuit designers to recognize quickly, understand, and choose optimal configurations.     Characterization of operational amplifiers is given by macro models and error matrices, together with measurement techniques for their parameters. Definitions are given for four types of operational amplifiers depending on the grounding of their input and output ports.

Many famous designs are evaluated in depth, using a carefully structured approach enhanced by numerous figures.  In order to reinforce the concepts introduced and facilitate self-evaluation of design skills, the author includes problems with detailed solutions, as well as simulation exercises.

Details

Published by: Springer

Publication Date: 2016-07-19

Format: Hardcover

ISBN-13: 9783319281261

DOI: 10.1007/978-3-319-28127-8

Dimensions: 235cm x155cm

Pages: 423
