5G and E-Band Communication Circuits in Deep-Scaled CMOS

Vigilante, Marco; Reynaert, Patrick

This book discusses design techniques, layout details and measurements of several key analog building blocks that currently limit the performance of 5G and E-Band transceivers implemented in deep-scaled CMOS. The authors present recent developments in low-noise quadrature VCOs and tunable inductor-less frequency dividers. Moreover, the design of low-loss broadband transformer-based filters that realize inter-stage matching, power division/combining and impedance transformation is discussed in great detail. The design and measurements of a low-noise amplifier, a downconverter and a highly-linear power amplifier that leverage the proposed techniques are shown. All the prototypes were realized in advanced nanometer scaled CMOS technologies without RF thick to metal option.

Details

Published by: Springer

Publication Date: 2019-06-06

Format: Paperback

ISBN-13: 9783319891927

DOI: 10.1007/978-3-319-72646-5

Dimensions: 235.0cm x155.0cm

Pages: 205.0
